OIML Single Point Platform Scale Load Cells AMF
Short Description:
Platform Scale Load Cells AMF
OIML approval,Application for platform Scale, Adopting high sensitivity Strain gauges，Made of high quality aluminum alloy with high strength, the device has sturdy structure which is available in the capacity from 50kg to 2ton. With the anodic oxidation treatment, it is resistant to corrosion, water and oxygen which is suitable for all kinds of environment.With the scientific and ergonomic design, it is convenient to use which can greatly save time, energy and money by improving the working efficiency. As well, it is available to provide the stable and excellent performance.It is a endurable product with extended service time that it can be used for a long period. And it is easy to maintain and clean, greatly prolonging its life span.
Specification
| Application |
Platform Scales, All kinds of Compression Testing Device |
| Rated Load | 50,100, 200, 300kg,500kg,750kg, 1t, 2t |
| Accuracy Class | 0.03%F.S |
| Sensitivity | 2.0±0.2mV/V |
| Creep (30mins) | ±166 ppm |
| Zero Balance | ±3% Emax |
| TC ZERO | ±17.5 ppm/℃ |
| TC SPAN | +20-+40℃: ±17.5 ppm/℃ |
| -10-+20℃: ±11.67 ppm/℃ | |
| Input Resistance | 404±15Ω |
| Output Resistance | 350±3Ω |
| Insulation resistance | ≥2000MΩ |
| Norminal Temperature Range | -10～+40℃ |
| Service Temp Range | -20～+50℃ |
| Safe load limit | 150%F.S |
| Over load limit | 200%F.S |
| Norminal of Range Excitation | 10～12V DC |
| Protection Class | IP65 |
| Material | Aluminium |
| Cable: Length; | 3m, Diameter: Ф5mm |
| Max Platform Size: | 600×600 (50-200kg)600×800 (300-500kg)1200×1200 (1-2t ) |
