Blending Beam Platform Scale Load Cells SMH
Short Description:
Blending Beam Platform Scale Load Cells SMH
Application for Blending Scale. Adopting high sensitivity Strain gauges，Made of high quality alloy steel with high strength, Laser Welded with IP68 waterproof grade .the device has sturdy structure which is available in the capacity from 50kg to 2ton. With the nickel plate treatment, it is resistant to corrosion, water and oxygen which is suitable for all kinds of environment. With the scientific and ergonomic design, it is convenient to use which can greatly save time, energy and money by improving the working efficiency. As well, it is available to provide the stable and excellent performance. It is a endurable product with extended service time that it can be used for a long period. And it is easy to maintain and clean, greatly prolonging its life span.
Specification
| Application |
Blending Scales, Packaging Scales, Dynamic Testing System, Platform Scales |
| Rated Load | 50,100,150, 200, 250, 300kg,500kg,750kg, 1t, 2t |
| Accuracy Class | 0.03%F.S |
| Sensitivity | 2.0±0.2mV/V |
| Non-linearity | ±0.03%F.S |
| Hysteresis Error | ±0.03%F.S |
| Creep (30mins) | ±0.02%F.S |
| TC ZERO | ±0.02%F.S/10℃ |
| TC SPAN | ±0.02%F.S/10℃ |
| Input Resistance | 400±2Ω |
| Output Resistance | 352±3Ω |
| Insulation resistance | ≥5000MΩ |
| Norminal Temperature Range | -10～+40℃ |
| Service Temp Range | -30～+70℃ |
| Safe load limit | 150%F.S |
| Over load limit | 200%F.S |
| Norminal of Range Excitation | 10～12V DC |
| Protection Class | IP65 |
| Material | Alloy Steel |
| Cable: Length; | 3m, Diameter: Ф5mm |
| Max Platform Size: | 400×400 (50-200kg)
600×800 (250-750kg) 1000×1000 (1-2t ) |
