Stainless Steel Single Point Load Cells SMK-SS
Short Description:
Stainless Steel Single Point Bench Scale Load Cells SMK-SS
OIML Approval,Appication for small Bench Scale, Adopting high sensitivity strain gauges，Made of high quality aluminum alloy with high strength, the device has sturdy structure which is available in the capacity from 8 to 100kg. With the anodic oxidation treatment, it is resistant to corrosion, water and oxygen which is suitable for all kinds of environment.With the scientific and ergonomic design, it is convenient to use which can greatly save time, energy and money by improving the working efficiency. As well, it is available to provide the stable and excellent performance.It is a endurable product with extended service time that it can be used for a long period. And it is easy to maintain and clean, greatly prolonging its life span.
Specification
|
Application : |
Blending scale, packing scale, dynamic testing system, platform scale |
|
Model : |
SMK-SS |
|
Capacity |
8,10,15, 20,30,50,60,100kg |
|
Output Sensitivity |
2.0± 0.2 MV/V |
|
Accuracy Class |
OIML C3 |
|
Creep(30 min) |
±0.03%F.S |
|
Non-linearity |
±0.03%F.S |
|
Hysteresis Error |
±0.03%F.S |
|
TC ZERO |
±0.02%F.S/10℃ |
|
TC SPAN |
±0.02%F.S/10℃ |
|
Input Impedance |
400 ± 20Ω |
|
output Impedance |
352 ± 5Ω |
|
Max Platform Size |
400×400MM |
|
Insulation Resistance |
≥5000 MΩ |
|
Recommend Excitation Voltage |
10V |
|
Maximum Excitation Voltage |
15V |
|
Operating Temperature Range |
-10～+40℃ |
|
Service Temperature Range |
-30～+70℃ |
|
Safe Overload |
150 %F.S |
|
Ultimate Overload |
300 %F.S |
|
Protection Grade |
IP65 |
|
Material |
Alloy Steel /Stainless Steel |
|
Cable Length |
Φ5× 1.8M |
