Stainless Steel Miniature Load Cells Sensor Force Transducer LWA

Short Description:



Stainless Steel Miniature Load Cells Sensor Force Transducer LWA
Feature:
Stainless Steel 17-4PH
Microstructure
Application:
It is widely used in force measurement applications in small installation space,
such as robot hand grip, pressure detection of hot and cold presses, and button feel testers.




Product Detail

FAQ

Product Tags

Specification:

Rated Load    3-100kg
Sensitivity       0.5-1.2mV/V
Accuracy Class  1.0%F.S.
Zero balance ±0.02 mV/V
Non-linearity ±1%F.S.
Hysteresis ±1%F.S.
Repeatability ±1%F.S.
Creep (30mins) ±1%F.S.
TCO          ±1%F.S/10℃
TC SPAN       ±1%F.S/10℃
Input resistance  350±10Ω
Output resistance  350±5Ω
Insulation resistance ≥5000MΩ (50DVC)
Temperature Range. Compensated -10~+40℃
Operating Temp Range             -20~+60℃
Safe load limit                      120%F.S
Over load limit   150%F.S
Recommend excitation              2.5-5V DC
Maximum excitation                  7V DC
Protection Class       IP65
Construction       Stainless Steel
Cable: Length Diameter:Ф2× 3m
