OIML Column Type Compression Load Cells ZSFY-A
Short Description:
OIML Column Type Compression Load Cells ZSFY-A
The OIML Compression Load Cell is made of high quality alloy steel or stainless steel with high strength that it is strong enough to make sure the stable operation. -Compact construction, it has small size which takes up little space. -Equipped with a handle, it is convenient to use with simple operation which can help to save time and energy. -It is scientifically designed that it is suitable for vehicle and hopper scales and vehicle testing facilities. -Manufactured with strict requirements, the OIML Compression Load Cell has endurable servce life with the resistance to corruption, dust and oxygen that it can be used over and over again, which is quite cost effective. -Waterproof, it is easy to maintain and clean, extending its life circle. And it is available maintain same after the long-term use. -Developed by the international certification of OIML, it has superior quality with elegant appearance and simple style
Specification
| Application : | Truck Scales, Railway Scales, Axle-load scales, Floor Scales |
| Model : | ZSFY-A |
| Capacity | 10,15,20,25,30,40,50T |
| Output Sensitivity | 2.0 ± 0.002 mV/V |
| Accuracy Class | C2-C5 |
| TCO | ±0.02 F.S/ 10 ℃ |
| TC SPAN | ±0.02 F.S/ 10 ℃ |
| Zero Balance | ±1.0 % F.S |
| Input Impedance | 700 ± 20 Ω |
| Output Impedance | 706 ± 7 Ω |
| Insulation Resistance | ≥5000 MΩ |
| Temperature Range Compensated | -10～+40℃ |
| Operating Temperature Range | -30～+70℃ |
| Recommend Excitation Voltage | 10～12V /DC |
| Maximum Excitation Voltage | 15V / DC |
| Safe Overload | 150 %F.S |
| Ultimate Overload | 250 %F.S |
| Protection Grade | IP68 |
| Material | Alloy Steel / Stainless Steel |
| Cable Length
|
φ5×8M (10T), φ5×10M (15T), φ5×14M (30T), φ5×16M (40-50T) |
