Low Profile Compression Load Cells LFB
Short Description:
Low Profile Compression Load Cells LFB
Which is made of high quality alloy steel with high strength that it is strong enough to make sure the stable operation. -Compact construction, it has small size which takes up little space.
Equipped with a handle, it is convenient to use with simple operation which can help to save time and energy.
It is scientifically designed that it is suitable for vehicle and hopper scales and vehicle testing facilities.
Manufactured with strict requirements, Low Profile Compression Load Cells has endurable servce life with the resistance to corruption, dust and oxygen that it can be used over and over again, which is quite cost effective.
Waterproof, it is easy to maintain and clean, extending its life circle. And it is available maintain same after the long-term use.
Developed by the international certification of CE, it has superior quality with elegant appearance and simple style.
Specification
| Application: | Axle-load scales, Warehouse Scales, Test Equipment |
| Model: | LFB |
| Capacity | 25, 50, 60,100KLB |
| Output Sensitivity | 4.0± 0.005 mV/V |
| Total Error | ± 0.02 %F.S, ± 0.05 %F.S, ± 0.1 %F.S |
| Creep (30 min) | ± 0.03 %F.S/30 Mins |
| TCO | ±0.02 F.S/ 10 ℃ |
| TC SPAN | ±0.02 F.S/ 10 ℃ |
| Zero Balance | ±1.0 % F.S |
| Input Impedance | 400 ± 10 Ω |
| Output Impedance | 352 ± 2 Ω |
| Insulation Resistance | ≥5000 MΩ |
| Recommend Excitation Voltage | 10～12V |
| Maximum Excitation Voltage | 15V / DC |
| Operating Temperature Range | -30～+70℃ |
| Safe Overload | 100 %F.S |
| Ultimate Overload | 120 %F.S |
| Protection Grade | IP67 |
| Material | Alloy Steel |
|
Cable Length |
φ6×12M |
